    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Ask Lasest Price
    Brand Name : Sino-holyson
    Certification : CE ISO9001
    Supply Ability : 500 sets/year
    Price : $25,500.00 - $28,500.00/sets
    Delivery Time : 40 works days
    Payment Terms : TT/LC
    • Product Details
    • Company Profile

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Sino-Holyson HSJZ-53/128 Size 250-300mm PVC Wall Panel Making Machine for WPC Profiles
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    Product Description

    PVC Wall / Ceiling Panel Making Machine


    General Introduction:


    The equipment consists of conical twin-screw extruder, vacuum shaping table, tractor, cutter, and stacker. It has high-techlaser tracking device exclusive, to ensure not only extrude pvc ceilings with high quality and output also greatly reduce the cost of production, which get appreciations from customers.


    Features and Application:


    1. The equipment adapts to various formulations, the ratio of calcium can be increased up to 50%- -250%,while the required accessories can be reduced by 30%.

    2. The ceiling the extruder products has an exquisite appearance and uniform plasticization.

    3. Laser tracking eliminates problems regarding the extrusion flow rate, whichelps achieve automation of the entire extrusion process.

    4. The PVC ceiling extrusion machine has auto-alarm functions in case of emergency, through the use of PID controller. Which is mainly used in the area of pvc ceiling, integrated ceiling, luggage board, ceiling corner etc.

    HSJZ-51/105
    HSJZ-53/128
    HSJZ-65/132
    Model
    160-250mm
    200-300mm
    250-400mm
    Motor Power(kw)
    18.5/22
    30
    37
    Output Range(kg/h)
    80-120
    100-150
    150-250
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    Detail Images

    HSJZ-53/128 Twin Screw Extruder


    HSJZ-53/128mm Conical Twin Screw Extruder


    This Extruder is designed specially for processing Higher Percent Calcium Mixed PVC Material, to manufacture PVC Wall/Ceiling Panels. The Extruder installs with 30kw driving motor , which will produce 700-1000sqm panels. Our SCREW & BARREL Sets is specially designed for 200-260% Calcium mixed. It has the advantages of high tenacity, high impact, good bending performance, high temperature resistance, etc.kw


    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Two Cavity Mould


    Angle Line U/L Shape


    This angle line moulds are designed into two cavity to improve the production efficiency. Compare with single screw extruder work with single cavity mould, this choice will greatly reduced the production cost.


    U/L Shape Angle Line

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    U/L Shape Angle Line
    Totally 2 pieces Angle Line moulds
    L-25*25mm
    U-9mm

    Vacuum Cooling Platform


    Vacuum Cooling Platform

    This unit is mainly for cooling and shaping the panels after the extrusion mould. It is installed with 4kw vacuum pump and 3kw water pump, for reliable production.

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Inline Film Laminating Machine


    This unit is specially for wall and ceiling panel production. It's a perfect match to the shape of the panel. The pressing rubber wheels direction or angle can be adjusted accordingly as per panel design. With a higher speed production, makes it very effective for the panel suppliers.

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Panel Stacker


    This unit is mainly for collecting the panels after proudction. It will discharge the panels automatically and piles the panels into bundle.

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    Downstream Machine

    Higher Speed PVC Mixer Machine


    This unit is mainly for collecting the panels after proudction. It will discharge the panels automatically and piles the panels into bundle.

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    Certifications
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
    Our Service
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    Pre-Sales Service

    * Inquiry and consulting support.

    * Sample testing support.

    * View our Factory.

    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles

    After-Sales Service

    * Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.

    Packing & Delivery
    250-300mm PVC Wall / Ceiling Panel Making Machine for WPC Profiles
